整车参数Specifications |
||
|
外型尺寸Exterior dimensions(mm) |
3380*1330*1940mm |
|
|
整备质量Curb mass(kg) |
700kg |
|
|
最大总质量Max.total mass(kg) |
1000kg |
|
|
最高车速Max.speed(km/h) |
30km/h |
|
|
续航里程Driving Mileage(km) |
80-100km |
|
|
前轮距Front tread (mm) |
1100mm |
|
|
后轮距Rear tread(mm) |
1200mm |
|
|
最大爬坡度Grade capability(%) |
25% |
|
|
百公里耗电Energy consumption(kwh) |
>15 |
|
|
乘员数(含驾驶员)Rated capacity(including driver) |
4人 |
|
|
悬架(前/后) Suspension(front/rear) |
扭杆弹簧独立悬架/钢板簧 |
|
|
制动器型式Brake type |
前碟刹/后鼓刹 |
|
|
变速器型式Transmission case type |
无级变速 |
|
|
轮胎规格Tire type |
175/70R14 |
|
|
最小离地间隙Min.Ground clearance (mm) |
150mm |
|
|
动力配置Drive system |
||
|
驱动电机Motor |
类型Motor type |
直流他励电机 |
|
功率Powe r(kw) |
4KW |
|
|
电压Voltage (V) |
48V |
|
|
转矩Torque (N.m) |
13.65n.m |
|
|
动力电池 Battery |
类型Type |
铅酸蓄电池 |
|
电压Voltage (V) |
6V |
|
|
容量Capacity (AH) |
190A |
|
|
控制器 Contorller |
额定直流电压 High voltage rated DC voltage (V) |
48V |
|
峰值电流有效值 Peak current virtual value (A) |
400A |
|
